Short Report – QA/QC Meeting Oct 2022

Meeting Date: 12 Oct 2022



Talking Points

  • FluxCoffee: separate meetings to discuss data related issues, e.g. flux processing, started and will continue to take place, next meeting will be longer 2-3h.
  • MeteoScreening using Jupyter notebooks is working, but currently the SRPs cannot use it due to security related issues.
  • Automatic flux calculations will be started soon, SRPs will be required to check fluxes regularly and give OK in a new table, similar to what we do for logger and meteo checks here: QA/QC Check – Weekly
  • Checking recent fluxes from our stations
  • Checking recent meteo data from our stations



General Info

  • If you are (Tech-)SRP, please attend QA/QC meetings or tell LH if you can’t, needed for planning of the meetings.
  • SRP & Tech-SRP: please prepare short statement about your site and send to to LH (max. 2 sentences)
  • The purpose of QA/QC meetings is to check on current, incoming data. SRPs choose specific issues we should look at together and discuss in the group. Fluxes are checked if the respective SRP wishes to do so.
  • There is a list of known variable abbreviations that you can use in case you wonder what an abbreviation means: Variable Abbreviations
  • Check of EC raw data files:
    • Recommended check for SRPs and T-SRPS: take a look at EC raw data files and check if they look OK
    • Current EC raw data files are automatically converted to ASCII each day (done by the Python script bico)
    • Files and their plots can be found here, e.g. for CH-LAS:
      • gl-processing\CH-LAS_Lae-Subcanopy\20_ec_fluxes\2022\raw_data_ascii
  • Weekly flux calculations on the RDS:
    • Please calculate fluxes and check them once per week, or more often if you wish to do so.
    • If you cannot calculate the fluxes, try to find a substitute, e.g. LH.
    • Please move your Level-0 results from the RDS to the respective Level-0 folder.
    • Automatic upload of Level-0 fluxes to the database will be implemented soon.
  • The folder P:\Flux\RDS_calculations is a temporary folder. Please move Level-0 flux calculations (preliminary fluxes) to the Level-0 folder on gl-processing. For example, for CH-CHA move files to Z:\CH-CHA_Chamau\20_ec_fluxes\2022\Level-0 (gl-processing is mounted as drive Z in this example).
  • List of QA/QC Meeting dates: QA/QC Meetings 2022



 Participants

LH, LK, LS, AS, IF, YW, FT, RM, TB (9)



Meteo Data

Grafana allows us to check meteo data from multiple stations in one plot. Both SW_IN and TA are very important variables, make sure to check them regularly.

Air Temperature

Radiation

Precipitation

Precipitation: Note that there is a data gap in CH-CHA data that was not corrected here.





Recent Fluxes



ALL SITES

CO2 flux



CH-AWS

Site Info

Short data gap in March due to software issues. CO2 uptake increasing until June, then mid-June becomes a CO2 source, probably due to grazing (and/or high air temperatures).

CO2 flux



CH-CHA

Site Info

Very clear and consistent CO2 uptake since first day of the year. Fertilization on 14.3., rain on 15.3. (only rain event in March). N2O and CH4 fluxes nearly complete, only one 24h-gap so far this year. Very obvious sharp decrease of CO2 update after the mowing events. Five mowing events so far this year (May 10th, June 10th, July 6th, Aug 9th and Sep 21st). The QCL instrument for N2O and CH4 measurements was removed from the site in July. N2O emission peak around the July 1st.

CO2 flux



CH-DAV

Site Info

EC system runs well, but there was an issue with one of the sonic transducers (it popped out of the housing, found 9 Feb 2022, transducer was pushed back in), no issue visible in data. Sonic was replaced on 8 Mar 2022 (HS-100). CO2 uptake is consistently low for this time of the year. This summer was the hottest summer so far since 1997 (up until 11 Aug).

CO2 flux



CH-DAS

Site Info

After snowmelt (in April?), clear net emission of CO2, see the red cumulative curve in the lower left corner of this plot:

CO2 flux





CH-FRU

Site Info

High CO2 uptake, few gaps. Harvest in June (not confirmed yet), approx. at the same time as the very hot day (19 June 2022). Harvests clearly visible.

CO2 flux



CH-LAE

Site Info

Unknown data format between mid-December and start of February, we will try find out the format. Data gap in February due to calibration. An interesting phenomena was decrease in sensible heat in May as the energy was used more for latent heat. Strongly reduced CO2 uptake during the heatwave, clearly visible after mid-July.

CO2 flux



CH-LAS

Site Info

CH-LAS recorded the highest VPD across all sites: 53.5 hPa on 4 Aug 2022.

End of April beginning of May the cumulative of CO2 over-passed the zero line, then there was a small pick of positive NEE (but we have some data gaps there) and after the NEE over-passed zero line again. As soon as the tree leaves came out in mid May the uptake of wild garlic decreased and the forest floor became a carbon source again.

CO2 flux



CH-OE2

Site Info

CH-OE2 is currently a temporary grassland. Already very clear CO2 uptake during the day since start of year. First cut of the temporary grassland on 14 May. Second cut of the grass on 25 June. Third cut on the 8 August. VPD was > 46 hPa over the summer.

CO2 flux



Last Updated on 30 Oct 2022 12:10
